E730 Series HVLS Fans

E730 Series HVLS Fans

The new generation Vindus E730 Series HVLS fans feature a high-volume, low-speed design powered by an advanced Permanent Magnet Synchronous Motor(PMSM). With diameters ranging from 4.9m(16ft) to 7.3m(24ft), these fans incorporate a new-generation integrated variable frequency controller developed specifically for large fan applications, allowing for one-touch access to current, voltage, and speed information. Equipped with an intelligent touch screen,the system can support wireless centralized control of upto 48 units(optional), eliminating the need for extensive wiring. Through optimized design,the E730 series fans are lighter,more cost-effective, and offer a higher return on investment.

In summer,the forward rotation provides a comfortable,quiet airflow,effectively reducing perceived temperatures by 3-7°C.During winter,reverse rotation eliminates thermal stratification, balancing temperatures between upper and lower levels. The E730 series is ideal for large spaces with ceiling heights ranging from 5 to 13 meters.

Inquire Now

product details Features Controller Applications Inquire Now

Product Details

Model/Performance	Diameter	Nuber of Blades	Weight	Max Rotation Speed	Covered Area	Recommended Blade Height	Power Usage Top speed
E730-16	4.9m	5	80kg	78rpm	600 m²	4-8m	640W
E730-18	5.5m	5	84kg	69rpm	750 m²	5-9m	720W
E730-20	6.1m	5	98kg	60rpm	920 m²	6-10m	680W
E730-24	7.3m	5	103kg	57rpm	1300 m²	7-13m	1040W
E780-24	7.3m	5/6	113kg	57rpm	1300 m²	7-15m	1100W

General Specifications
Voltage	208VAC-240VAC Single Phase, 50Hz/60Hz
Rated Power	1500W/1300W/750W
Sound @Max Speed	<50dBA
IP Rating	IPX5 Indoor/Outdoor
Temperature Rating	-25℃～45/55℃
Certifications	CE, EMC, IEC, MD, LVD, RoHS Certification
Controller	integrated variable frequency controller
Warranty	3 Years on all Parts -Extended Warranty Optional

Motor Technology: Direct drive technology

Advantage

No oil

No seals to leak

Only 2 moving parts

Low noise

Low energy consumption

Low weight

Permanent Magnet Synchronous Motor (PMSM)

Advantage

Lighter

3-year warranty

Cost effective

Scalable torque

Low energy losses

Features

5 anodized aluminium blades

Quick and easy installation

Energy-efficient operation

Network multiple fans

8 speed settings

Safety cable, 5 blade retainer links for extreme safety

Conforms to CE, EMC, IEC, MD, LVD, RoHS standards

Multiple redundancies in allcritical components, including blades, motors, electronics, and mount

Maximizes HVAC system efficiency

Lower energy consumption

Reduces energy costs

Reduces your carbon footprint

Improves indoorair quality

Improves thermal comfort in summer and winter

Quiet operation reduces mental fatigue

Reduces mental fatigue

Increases worker productivity

Controller

Fan Controller

Compatible with M650 and M750

Integrated wall mount design

LCD display

Up to 20 Vindus fans can be easily operated using this digital controller

Easy command for forward functions with 7 speed levels

Multi-function potentiometer with LED status indicator

Wireless remote control (optional)

Built-in smart internet of things (IoT) module (optional)

Applications

Wide Applications of Vindus HVLS Fans in Industrial & Commercial Settings

The large-scale, energy-efficient HVLS fans from Vindus Fans are designed to enhance air circulation, temperature control, and energy savings across a variety of industrial and commercial spaces. These high-volume, low-speed (HVLS) fans provide uniform airflow, improving comfort, productivity, and operational efficiency in the following environments:

Warehouses & Logistics Centers

Optimized air circulation helps prevent heat buildup, ensuring stable inventory conditions and improving worker efficiency.
Reduces humidity levels, protecting stored goods from moisture damage.

Manufacturing Plants & Factories

Enhances factory ventilation, maintaining stable temperatures for precision manufacturing and worker safety.
Reduces HVAC energy consumption, lowering operational costs.

Sports Centers, Gymnasiums & Indoor Arenas

Even air distribution creates a comfortable environment for athletes and spectators.
Helps regulate humidity and temperature, preventing overheating during intense physical activities.

Agricultural Barns & Livestock Facilities

Improves air quality by preventing stagnant air, reducing heat stress for animals.
Helps maintain optimal airflow, creating better conditions for crop storage and livestock health.

Retail Spaces, Shopping Malls & Commercial Buildings

Enhances customer comfort with consistent air circulation, making shopping environments more pleasant.
Supports HVAC systems by reducing temperature fluctuations and minimizing energy costs.

Exhibition Halls & Convention Centers

Controls humidity and airflow, ensuring exhibits, artifacts, and displayed products are protected from moisture damage.
Provides a more comfortable atmosphere for visitors at large-scale events.

Automotive Repair Shops & Industrial Workshops

Regulates temperatures to create ideal working conditions, preventing excessive heat buildup.
Ensures equipment longevity by reducing temperature fluctuations in automobile service centers.

Food Processing & Cold Storage Facilities

Maintains consistent airflow, helping preserve food quality by controlling humidity levels.
Ensures safe and hygienic working conditions, reducing condensation and mold risks.

Educational Institutions (Schools, Universities, Training Centers)

Enhances air circulation in lecture halls, auditoriums, and cafeterias, creating a healthier learning environment.
Supports temperature control in gymnasiums and multi-purpose halls, ensuring comfort for students and staff.
